B&c 15DS115
B&c
B&c 15DS115
This next evolution subwoofer uses a new, longer, four layer aluminum voice coil. The result is more energy in the gap, less heat, higher sensitivity, higher power handling, lower distortion and better overall performance. The 15DS115 features a 40mm long, 4.5 inch diameter (116mm) Copper Clad Aluminum Wire voice coil. With a 1600watt AES power rating, 97 dB sensitivity, and over 14 mm of Xvar, this high energy subwoofer is a significant step forward from similar models in the B&C range.
- 3200 W continuous program power capacity
- 116 mm (4.5 in) four layer aluminum voice coil
- 35 - 1000 Hz response
- 97 dB sensitivity
- 60 mm peak-to-peak excursion before damage
- Neodymium magnet allows a very high force factor and linear excursion
- Double silicone spider with optimized compliance
- Ventilated voice coil gap for reduced power compression
- Aluminium demodulating ring for very low distortion
Specifications
- Nominal Diameter380 mm (15.0 in)
- Nominal Impedance8 Ω
- Minimum Impedance7.2 Ω
- Nominal Power Handling11600 W
- Continuous Power Handling23200 W
- Sensitivity397.0 dB
- Frequency Range35 - 1000 Hz
- Voice Coil Diameter116 mm (4.5 in)
- Winding MaterialAluminium
- Former MaterialGlass Fibre
- Winding Depth40.0 mm (1.57 in)
- Magnetic Gap Depth14.0 mm (0.55 in)
- Flux Density0.8 T
Design
- Surround ShapeTriple Roll
- Cone ShapeRadial
- Magnet MaterialNeodymium Inside Slug
- SpiderDouble Silicone
- Pole DesignT-Pole
- Woofer Cone TreatmentTWP Waterproof Both Sides
- Recommended Enclosure80.0 dm3 (2.83 ft3)
- Recommended Tuning40 Hz
Parameters4
- Resonance Frequency33 Hz
- Re4.9 Ω
- Qes0.18
- Qms5.2
- Qts0.17
- Vas94.0 dm3 (3.32 ft3)
- Sd855.0 cm2 (132.53 in2)
- η₀1.9 %
- Xmax16.5 mm
- Xvar14.0 mm
- Mms254.0 g
- Bl38.7 Txm
- Le4.5 mH
- EBP183 Hz
